What the Supercam S350 is made of
99 documented parts and 60 photos, from recovered wreckage. Each part gives its marking, maker and country where known, and links the record it comes from. The system itself: Supercam S350.
Where the parts were made
- United States of America 43
- Wolfspeed, Inc. (Cree, Inc.), ON Semiconductor (ONSEMI), Vishay Intertechnology, Inc., Integrated Silicon Solution (Ingenic Semiconductor), Standard Microsystems Corp (SMSC), Bourns Inc, Analog Devices, Texas Instruments, Atmel (Microchip Technology), LATTEPANDA Сomp., Maxim Integrated Products (Analog Devices), Adesto Technologies (Dialog Semiconductor - Renesas Electronics), Semtech Corporation, National Semiconductor (Texas Instruments), TTi Inc., Wolfspeed, RSM Electron Power, Inc.
- People's Republic of China 15
- Tiger Motor International Co.,Ltd, Espressif Systems, MORNSUN Guangzhou Science & Technology Co., Ltd., WitMotion Shenzhen Co, Ltd., Scorpion Power System, Nanchang Sanrui Intelligent Technology Co., Ltd., Not identified, Real Support Electronic Co., Ltd., IFlight iPower
- Switzerland 10
- STMicroelectronics, U-blox, Traco Power
- Netherlands 6
- NXP Semiconductors
- Republic of Korea 5
- Macro Image Technology, INC., Dyna Logic, KT&C CO LTD, LG
- Germany 5
- Infineon Technologies, EPCOS AG
- Japan 5
- Murata, Kenko Co., Ltd.
- Ireland 3
- TE Connectivity
- Taiwan 3
- AVerMedia Technologies, Tai-Shing Electronics Components Corp.
Sources
- HUR War & Sanctions: UAV "Supercam S350", tail number 2308S350FFC53535 · українською
- HUR War & Sanctions: UAV "Supercam-S350" (April 2023) · українською
- HUR War & Sanctions: "Supercam S350" UAV №2212S350SP19017 · українською
- HUR War & Sanctions: "Supercam-S350" UAV · українською
- Open Source Munitions Portal — search its munition identification records
Ukrainian pages read alongside the English: same items, markings and text.
UAV "Supercam S350", tail number 2308S350FFC53535 record ↗
Camcorder VTC-Z7833H
Cascade video signal amplifier
Video transmitter module "Sector AHD Tx1"
ISM radio bridge
SAU 350 Unit
- YE04
22K G4
ASY5
4-bit bidirectional voltage-level translator
record ↗
- adesto2151
25DF321A
SN
Serial Flash Memory 32Mbit
record ↗
- LPC4337JBD144
PSNG00.00 2D
ESD21270A
A 32-bit microcontroller
record ↗
- SN74HCT541 / SN54HCT541
HT541
13KG4
CN2C
Octal Buffer and Line Driver With 3-State Outputs
record ↗
- LMZ14201
Power module
record ↗
- P5501TG
PNP12
Transistor
record ↗
- ADM3315EA
#2229
Serial Port Transceiver
record ↗
- 4525D 5AI
0010 2240
0171 19903
Pressure sensor
record ↗
- SCC2230-D08
Combined gyroscope and 3-axis accelerometer with digital SPI interface
record ↗
Video signal processing and shaping board
- BNX012
24
Electromagnetic interference filter
record ↗
- 8M12BG
RPL05
Positive VoltageRegulator
record ↗
- MAX3232
ESE 2240
Multichannel RS-232 line driver and receiver
record ↗
- MAX7456
EUI
NEP 2319
On-screen display video generator
record ↗
- TRR1C05D00
C22J
Relay
record ↗
- URB2405YMD-15WR3
Voltage converter
record ↗
- LPC1768FBD100
SSW6521 19
ZSD220SA
Microcontroller
record ↗
- STM32F100RBT6B
GQ20G 93 11
CHN GQ 239
A 32-bit microcontroller
record ↗
GPS receiver
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
UAV "Supercam-S350" (April 2023) record ↗
Command and telemetry radio module
Automatic control system unit (autopilot)
Photo: HUR War & Sanctions
GPS receiver based on Ublox GPS module
GPS приймач на базі GPS-модулю Ublox
NEO-M9N-00В-00
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
Photo: HUR War & Sanctions
"Supercam S350" UAV №2212S350SP19017 record ↗
Transceiver module of the command and telemetry radio line
- SX 1276
Chip
record ↗
Target acquisition module
Gyro-stabilised suspension
Video interface converter
Video signal processing and shaping board
Video information transmission system Power amplifier
Flight controller with navigation system
- T25D321A Chip record ↗
- SN65VND232 Tyre driver record ↗
- STM8S208 Microcontroller record ↗
- P5501TG Transistor record ↗
- NEO-M9N-00B Navigation module record ↗
- ADM3815EA Chip record ↗
- 74HT541 Eight-bit buffer record ↗
- SCC2230-D08 Microelectromechanical position sensor record ↗
- LMZ14202 Power supply module record ↗
- 13156PN11GA Magnetic field sensor record ↗
- 4525DO-DS5AI001DP Microelectro-mechanical barometric height sensor record ↗
- ARM7 NXP LPC4337JBD144 Microcontroller architecture record ↗
- 4525DO-DS5AI001DP Pressure sensor record ↗
Voltage sensor
Optoelectronic system Course camera
Оптико-електронна система Курсова камера
KPC-C700PUB
Photo: HUR War & Sanctions
Humidity and temperature sensor on board
Датчик вологості та температури за бортом
STH21
"Supercam-S350" UAV record ↗
LattePanda mini computer (computing unit)
Міні-комп’ютер LattePanda (обчислювальний блок)
Electric brushless cardan motors
Електричні безщіткові карданні двигуни
iFlight iPower GM5208-12 та GM3506
Part records and photos: HUR War & Sanctions, Ukraine's Defence Intelligence database of foreign components found in Russian weapons, and the other sources named on each part. A marking, date code or country is given as the source records it.
