What the Ka-52 is made of

127 documented parts and 127 photos, from recovered wreckage. Each part gives its marking, maker and country where known, and links the record it comes from. The system itself: Ka-52.

Where the parts were made

United States of America 119
Altera Corporation (Intel), Maxim Integrated Products (Analog Devices), Analog Devices, Micron Technology, Merrimac Industries Inc., Texas Instruments, Pulse Electronics Corporation, Integrated Circuit Systems, Atmel (Microchip Technology), Xilinx Inc. (AMD), Alliance Memory Inc., Intel Corporation, NVE Corporation, Linear Technology Corporation (Analog Devices), Holt Integrated Circuits, Inc., Cortina Systems, Spansion (Cypress Semiconductor, Infineon Technologies), Cypress Semiconductor (Infineon Technologies)
Japan 3
Renesas, Murata, Sumida Corporation
Taiwan 2
Transcend, Macronix International
Germany 1
Infineon Technologies
France 1
Thales
People's Republic of China 1
Xiamen Weigao Communication Electronic Technology Co., Ltd.

Sources

Ukrainian pages read alongside the English: same items, markings and text.

Combat attack helicopter Ka-52, code: "Alligator", index "800.06"

Gyro-stabilized optical-electronic system GOES-451.10 (Thermal imaging channel TPVK-24NS)

  • Board № AD3.031.074
  • Altera EPC16QI100N Attachment of EPC divisions into two main blocks - configuration controller and flash memory Altera Corporation (Intel)United States of Americarecord ↗ Attachment of EPC divisions into two main blocks - configuration controller and flash memory, marked Altera EPC16QI100N
  • ALTERA Stratix EP1S25F102016 L CEA901419A Процессор Altera Corporation (Intel)United States of Americarecord ↗ Процессор, marked ALTERA Stratix EP1S25F102016 L CEA901419A
  • Board № АМНК.431156.003 №317
  • АD828A #1140 36156 Dual low-power video amplifier Analog DevicesUnited States of Americarecord ↗ Dual low-power video amplifier, marked АD828A #1140 36156
  • Board № АМНК.431156.001 №317
  • ICS307M-02 CL6000070 1027 Last programmed clock speed Integrated Circuit SystemsUnited States of Americarecord ↗ Last programmed clock speed, marked ICS307M-02 CL6000070 1027
  • ATMEL ATMEGA1281V 8AU 1206 High performance 8-bit microcontroller with low power consumption Atmel (Microchip Technology)United States of Americarecord ↗ High performance 8-bit microcontroller with low power consumption, marked ATMEL ATMEGA1281V 8AU 1206
  • SPARTAN XC2S50 TQG144AMS1009 A2470831A 5C integrated circuit Xilinx Inc. (AMD)United States of Americarecord ↗ integrated circuit, marked SPARTAN XC2S50 TQG144AMS1009 A2470831A 5C
  • ALLIANCE AS7C34096-15TC 1026 VT-401N 715001A High performance CMOS static storage attachment Alliance Memory Inc.United States of Americarecord ↗ High performance CMOS static storage attachment, marked ALLIANCE AS7C34096-15TC 1026 VT-401N 715001A
  • Board on the body № 1215.11151000 № Л05
  • OUAOBI9 ULN2803AG n/a Texas InstrumentsUnited States of Americarecord ↗ n/a, marked OUAOBI9 ULN2803AG
  • RS-232 із захистом MAX232E Sub-driver/receiver Texas InstrumentsUnited States of Americarecord ↗ Sub-driver/receiver, marked RS-232 із захистом MAX232E
  • Infineon SAF-XC164CS -16F40F 16-bit single-chip microcontroller Infineon TechnologiesGermanyrecord ↗ 16-bit single-chip microcontroller, marked Infineon SAF-XC164CS -16F40F
  • Board №1191.14260610 №Г34153 (05.15)
  • EN87C198KC20 L710QA53 microcontroller Intel CorporationUnited States of Americarecord ↗ microcontroller, marked EN87C198KC20 L710QA53
  • 0UAQB19 ULN2803AG High-voltage, high-voltage array of Darlington transistors Texas InstrumentsUnited States of Americarecord ↗ High-voltage, high-voltage array of Darlington transistors, marked 0UAQB19 ULN2803AG
  • Board № 1141.11601010 № Б04.13.4 .12
  • AD2899A 1103 AF76172 Programmable sinusoidal generator Analog DevicesUnited States of Americarecord ↗ Programmable sinusoidal generator, marked AD2899A 1103 AF76172
  • AD2S90 APZ 0834 1503712.1 Analog - digital 12 bit converter Analog DevicesUnited States of Americarecord ↗ Analog - digital 12 bit converter, marked AD2S90 APZ 0834 1503712.1
  • Atmel ATMEGA128 16AU 1121 8-bit microcontroller with 128 KB programmable flash Atmel (Microchip Technology)United States of Americarecord ↗ 8-bit microcontroller with 128 KB programmable flash, marked Atmel ATMEGA128 16AU 1121
  • AD022A LBN0751 40533 Digital magnetic field sensor NVE CorporationUnited States of Americarecord ↗ Digital magnetic field sensor, marked AD022A LBN0751 40533
  • Product №1131.5300000 №00515
  • MAXIM MAX1480AEPI 1052 Integrated circuit, as recognized for duplex communication Analog DevicesUnited States of Americarecord ↗ Integrated circuit, as recognized for duplex communication, marked MAXIM MAX1480AEPI 1052
  • ALTERA MAX EPM7128SQI100-10N HEU 241213A VE124843083 3N2WA200M Processor Altera Corporation (Intel)United States of Americarecord ↗ Processor, marked ALTERA MAX EPM7128SQI100-10N HEU 241213A VE124843083 3N2WA200M
  • Power modules Products MDM40-1В3,3МУВ 1405 No. 140187502, MDM40-1В05МУВ 1404 No. 140141814
  • LINEAR LT1764A EQ 3284332 LDO-regulatory controller, optimized for a quick reception of the input. Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ LDO-regulatory controller, optimized for a quick reception of the input., marked LINEAR LT1764A EQ 3284332
  • Board № АD2.572.073 №14035
  • LINEAR LT1370 HVIR 0110053 LDO High efficiency switching regulator Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ LDO High efficiency switching regulator, marked LINEAR LT1370 HVIR 0110053
  • Board № AD2075048 № 14029
  • Thales RM2-71/02 Stirling rotary cooler ThalesFrancerecord ↗ Stirling rotary cooler, marked Thales RM2-71/02
  • 2T716Б1 Transistor Xiamen Weigao Communication Electronic Technology Co., Ltd.People's Republic of Chinarecord ↗ Transistor, marked 2T716Б1
  • 09SFFT8 A26LV32EMP G4 Differential line driver with 3-way output Texas InstrumentsUnited States of Americarecord ↗ Differential line driver with 3-way output, marked 09SFFT8 A26LV32EMP G4
  • TMS 390F2811PBKS CG-32A372W G4 DSP processor Texas InstrumentsUnited States of Americarecord ↗ DSP processor, marked TMS 390F2811PBKS CG-32A372W G4
  • LINEAR LT1764A EQ 3284332 Regulatory controller, optimization for swedish reception Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ Regulatory controller, optimization for swedish reception, marked LINEAR LT1764A EQ 3284332
  • Board № AD3.031.074
  • RS232/V.28 ADM322121 ARUZ 1345 SWID-coded two-channel interface component Analog DevicesUnited States of Americarecord ↗ SWID-coded two-channel interface component, marked RS232/V.28 ADM322121 ARUZ 1345
  • 16CYFXK G4 CW244A 16-bit buffer/driver Texas InstrumentsUnited States of Americarecord ↗ 16-bit buffer/driver, marked 16CYFXK G4 CW244A
  • LINEAR LT1764A EQ 4035865 Regulatory controller, optimization for swedish reception Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ Regulatory controller, optimization for swedish reception, marked LINEAR LT1764A EQ 4035865
  • ADS850Y05A4Y8T Analog-Digital Converter Texas InstrumentsUnited States of Americarecord ↗ Analog-Digital Converter, marked ADS850Y05A4Y8T
  • ADV7123KSTZ140 1416 Triple high-speed digital-to-analog converter on one monolithic chip Analog DevicesUnited States of Americarecord ↗ Triple high-speed digital-to-analog converter on one monolithic chip, marked ADV7123KSTZ140 1416
  • IDT 70V7339S166BCI 751413P W73436FN1 IND CO High-speed, synchronous, switchable, two-port, static OZP RenesasJapanrecord ↗ High-speed, synchronous, switchable, two-port, static OZP, marked IDT 70V7339S166BCI 751413P W73436FN1 IND CO
  • A6E3 DSP ТМS320C6414GLZ C20-31AZ11W 2003 TI 62 High performance digital signal module with fixed point DSP Texas InstrumentsUnited States of Americarecord ↗ High performance digital signal module with fixed point DSP, marked A6E3 DSP ТМS320C6414GLZ C20-31AZ11W 2003 TI 62

Video switch digital VKM-Ts

  • Module with TCS board № 467229.007 сер. № 879
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectification and internal switches Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectification and internal switches, marked MAX1831 EEE 337
  • EPC54N 9501X Integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ Integrated circuit, marked EPC54N 9501X
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2
  • 1412 2-7 48LC4M32B2 P -6A IT L High-speed CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High-speed CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • EEPROM ALTERA ERM3064ATI44-10N S BCB77 1503A A high-performance CMOS-based programmable logic device (PLD). Altera Corporation (Intel)United States of Americarecord ↗ A high-performance CMOS-based programmable logic device (PLD)., marked EEPROM ALTERA ERM3064ATI44-10N S BCB77 1503A
  • 113B AXG Divider/adder Merrimac Industries Inc.United States of Americarecord ↗ Divider/adder, marked 113B AXG
  • LC125A 41AG P1YJ Quadruple tire buffer gate Texas InstrumentsUnited States of Americarecord ↗ Quadruple tire buffer gate, marked LC125A 41AG P1YJ
  • 113A AXF Divider/adder Merrimac Industries Inc.United States of Americarecord ↗ Divider/adder, marked 113A AXF
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2
  • ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K Processor (programmable gate matrix) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmable gate matrix), marked ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K
  • 1412 2-7 48LC4M32B2 -6A IT L High-speed dynamic random access memory Micron TechnologyUnited States of Americarecord ↗ High-speed dynamic random access memory, marked 1412 2-7 48LC4M32B2 -6A IT L
  • PULSE TM1062DVB2 1514-C CHINA Linear interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Linear interface module, marked PULSE TM1062DVB2 1514-C CHINA
  • Module with board № 467219.007 серійний номер № 990
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectification and internal switches Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectification and internal switches, marked MAX1831 EEE 337
  • EPC54N 9501X integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ integrated circuit, marked EPC54N 9501X
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • 1412 2-7 48LC4M32B2 P -6A IT L High resolution CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High resolution CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • EPROM ALTERA EPM3064A TI44-10N S BCB77 1503A Highly productive programming logic (PLD) based on CMOS Altera Corporation (Intel)United States of Americarecord ↗ Highly productive programming logic (PLD) based on CMOS, marked EPROM ALTERA EPM3064A TI44-10N S BCB77 1503A
  • 113B AXG Divider / sumator Merrimac Industries Inc.United States of Americarecord ↗ Divider / sumator, marked 113B AXG
  • LC125A 41AG P1YJ Two-fold bus buffer gate Texas InstrumentsUnited States of Americarecord ↗ Two-fold bus buffer gate, marked LC125A 41AG P1YJ
  • 113A AXF Divider / sumator Merrimac Industries Inc.United States of Americarecord ↗ Divider / sumator, marked 113A AXF
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K Processor (programmed gate array) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmed gate array), marked ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K
  • 1412 2-7 48LC4M32B2 -6A IT L Highly dynamic memory with sufficient access Micron TechnologyUnited States of Americarecord ↗ Highly dynamic memory with sufficient access, marked 1412 2-7 48LC4M32B2 -6A IT L
  • PULSE TM1062DVB2 1514-C CHINA Line interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Line interface module, marked PULSE TM1062DVB2 1514-C CHINA
  • Module with PCS board № 467219.006 сер. № 013
  • EPC54N 9501X integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ integrated circuit, marked EPC54N 9501X
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectifiers and internal jumpers Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectifiers and internal jumpers, marked MAX1831 EEE 337
  • LC125A 41AG P1YJ Two-fold bus buffer gate Texas InstrumentsUnited States of Americarecord ↗ Two-fold bus buffer gate, marked LC125A 41AG P1YJ
  • PULSE TM1062DSB2 1443-C CHINA Line interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Line interface module, marked PULSE TM1062DSB2 1443-C CHINA
  • ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K Processor (programmed gate array) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmed gate array), marked ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K
  • 1412 2-7 48LC4M32B2 P -6A IT L High resolution CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High resolution CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • ALTERA ERM3064A TI44-10N S BCB77 1503A Highly productive programming logic (PLD) based on CMOS Altera Corporation (Intel)United States of Americarecord ↗ Highly productive programming logic (PLD) based on CMOS, marked ALTERA ERM3064A TI44-10N S BCB77 1503A
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • EPC54N 9501X integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ integrated circuit, marked EPC54N 9501X
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectifiers and internal jumpers Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectifiers and internal jumpers, marked MAX1831 EEE 337
  • LC125A 41AG P1YJ Two-fold bus buffer gate Texas InstrumentsUnited States of Americarecord ↗ Two-fold bus buffer gate, marked LC125A 41AG P1YJ
  • PULSE TM1062DSB2 1443-C CHINA Line interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Line interface module, marked PULSE TM1062DSB2 1443-C CHINA
  • ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K Processor (programmed gate array) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmed gate array), marked ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K
  • 1412 2-7 48LC4M32B2 P -6A IT L High resolution CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High resolution CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • ALTERA ERM3064A TI44-10N S BCB77 1503A Highly productive programming logic (PLD) based on CMOS Altera Corporation (Intel)United States of Americarecord ↗ Highly productive programming logic (PLD) based on CMOS, marked ALTERA ERM3064A TI44-10N S BCB77 1503A
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • Module with PCS board № 467219.006 сер.№ 010
  • EPC54N 9501X integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ integrated circuit, marked EPC54N 9501X
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectifiers and internal jumpers Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectifiers and internal jumpers, marked MAX1831 EEE 337
  • LC125A 41AG P1YJ Two-fold bus buffer gate Texas InstrumentsUnited States of Americarecord ↗ Two-fold bus buffer gate, marked LC125A 41AG P1YJ
  • PULSE TM1062DSB2 1443-C CHINA Line interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Line interface module, marked PULSE TM1062DSB2 1443-C CHINA
  • ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K Processor (programmed gate array) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmed gate array), marked ALTERA Cyclone EP1C12F324І7N L BCD9S1507A MALAYSIA VCD9S88372 3P3LA5Y0K
  • 1412 2-7 48LC4M32B2 P -6A IT L High resolution CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High resolution CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2
  • ALTERA ERM3064A TI44-10N S BCB77 1503A Highly productive programming logic (PLD) based on CMOS Altera Corporation (Intel)United States of Americarecord ↗ Highly productive programming logic (PLD) based on CMOS, marked ALTERA ERM3064A TI44-10N S BCB77 1503A
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • Module with board № 467219.007 сер.№ 989
  • MAX1831 EEE 337 Low-voltage step-down regulator with synchronous rectifiers and internal jumpers Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Low-voltage step-down regulator with synchronous rectifiers and internal jumpers, marked MAX1831 EEE 337
  • EPC54N 9501X integrated circuit Altera Corporation (Intel)United States of Americarecord ↗ integrated circuit, marked EPC54N 9501X
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • 1412 2-7 48LC4M32B2 P -6A IT L High resolution CMOS dynamic RAM Micron TechnologyUnited States of Americarecord ↗ High resolution CMOS dynamic RAM, marked 1412 2-7 48LC4M32B2 P -6A IT L
  • EPROM ALTERA EPM3064A TI44-10N S BCB77 1503A Highly productive programming logic (PLD) based on CMOS Altera Corporation (Intel)United States of Americarecord ↗ Highly productive programming logic (PLD) based on CMOS, marked EPROM ALTERA EPM3064A TI44-10N S BCB77 1503A
  • 113B AXG Divider / sumator Merrimac Industries Inc.United States of Americarecord ↗ Divider / sumator, marked 113B AXG
  • LC125A 41AG P1YJ Two-fold bus buffer gate Texas InstrumentsUnited States of Americarecord ↗ Two-fold bus buffer gate, marked LC125A 41AG P1YJ
  • 113A AXF Divider / sumator Merrimac Industries Inc.United States of Americarecord ↗ Divider / sumator, marked 113A AXF
  • ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE Video codec Analog DevicesUnited States of Americarecord ↗ Video codec, marked ANALOG DEVICES ADV212BBCZ SURF -150 #1541 3304394.1 0.2 SINGAPORE
  • ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K Processor (programmed gate array) Altera Corporation (Intel)United States of Americarecord ↗ Processor (programmed gate array), marked ALTERA Cyclone EP1C12F324I7N L BCD9S1503A MALAYSIA VCD9S23706 3P3LA5E0K
  • 1412 2-7 48LC4M32B2 -6A IT L Highly dynamic memory with sufficient access Micron TechnologyUnited States of Americarecord ↗ Highly dynamic memory with sufficient access, marked 1412 2-7 48LC4M32B2 -6A IT L
  • PULSE TM1062DVB2 1514-C CHINA Line interface module Pulse Electronics CorporationUnited States of Americarecord ↗ Line interface module, marked PULSE TM1062DVB2 1514-C CHINA
  • Boards on the body of the VKM-Ts product
  • NTE0305MC G1415 Isolated DC/DC converters with one output MurataJapanrecord ↗ Isolated DC/DC converters with one output, marked NTE0305MC G1415
  • AT90CAN128 -16AU 1516 A334VA 16Kb/32Kb/64k ATMEL Flash System Programmable 8-Bit Microcontroller Atmel (Microchip Technology)United States of Americarecord ↗ 16Kb/32Kb/64k ATMEL Flash System Programmable 8-Bit Microcontroller, marked AT90CAN128 -16AU 1516 A334VA
  • Module with KUN-6 board № 468332.020 сер. № 894
  • 2R5 M1N Power inductor (smd type) Sumida CorporationJapanrecord ↗ Power inductor (smd type), marked 2R5 M1N
  • VP230 29M A3DK 3.3-V CAN transceiver Texas InstrumentsUnited States of Americarecord ↗ 3.3-V CAN transceiver, marked VP230 29M A3DK
  • LC125A 48AGP 1GG Quadruple tire buffer gate Texas InstrumentsUnited States of Americarecord ↗ Quadruple tire buffer gate, marked LC125A 48AGP 1GG
  • ATMEL AT90CAN128 -16AU 1417 9F4362 8-bit microcontroller with 16Kb/32Kb/64Kb flash system programming Atmel (Microchip Technology)United States of Americarecord ↗ 8-bit microcontroller with 16Kb/32Kb/64Kb flash system programming, marked ATMEL AT90CAN128 -16AU 1417 9F4362
  • 1339 3-2 48LC4M32B2 TG 7-IT G High-speed dynamic random access memory with an asynchronous interface Micron TechnologyUnited States of Americarecord ↗ High-speed dynamic random access memory with an asynchronous interface, marked 1339 3-2 48LC4M32B2 TG 7-IT G
  • ALTERA Cyclone II EP2C35F67218N K CBD9Y1425U KOREA VBD9Y62912 3R1KU41OD High performance programmable logic device Altera Corporation (Intel)United States of Americarecord ↗ High performance programmable logic device, marked ALTERA Cyclone II EP2C35F67218N K CBD9Y1425U KOREA VBD9Y62912 3R1KU41OD
  • A200 DSP TMS320C6713BGDP C20-35P00C8 3460141 Floating Point Digital Signal Processor (DSP) Texas InstrumentsUnited States of Americarecord ↗ Floating Point Digital Signal Processor (DSP), marked A200 DSP TMS320C6713BGDP C20-35P00C8 3460141
  • 404 G3 1763 Low noise, low droop micropower regulator Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ Low noise, low droop micropower regulator, marked 404 G3 1763
  • LV595A 43A99 PQX8 8-bit shift registers with 3-state output registers Texas InstrumentsUnited States of Americarecord ↗ 8-bit shift registers with 3-state output registers, marked LV595A 43A99 PQX8

On-board digital computer "Baguette-53-15"

  • Board decimal No. KMYV.687264.167 IZM.8
  • 3CAJ7KK G4 AL VTH162244 2.5-V/3.3-V 16-bit buffer/driver with 3-stage outputs Texas InstrumentsUnited States of Americarecord ↗ 2.5-V/3.3-V 16-bit buffer/driver with 3-stage outputs, marked 3CAJ7KK G4 AL VTH162244
  • XCV150 PQG240AFP1217 D1126873A Virtex Built-in integrated circuit Xilinx Inc. (AMD)United States of AmericaMade 2012record ↗ Built-in integrated circuit, marked XCV150 PQG240AFP1217 D1126873A Virtex
  • Board decimal number KMYV.687264.298 IZM.“3”
  • 17A9HPK G4 ALVTH16245 2.5-V/3.3-V 16-bit transceiver with 3-stage outputs Texas InstrumentsUnited States of Americarecord ↗ 2.5-V/3.3-V 16-bit transceiver with 3-stage outputs, marked 17A9HPK G4 ALVTH16245
  • ARINC 429 HI-8445 PST 1238 Integrated microcircuit - receiver line Holt Integrated Circuits, Inc.United States of Americarecord ↗ Integrated microcircuit - receiver line, marked ARINC 429 HI-8445 PST 1238
  • 41A35YK G4 ALVTH162244 2.5-V/3.3-V 16-bit buffer/driver Texas InstrumentsUnited States of Americarecord ↗ 2.5-V/3.3-V 16-bit buffer/driver, marked 41A35YK G4 ALVTH162244
  • Atmel AT49BV322DТ 70TU 1116 32 megabit flash memory Atmel (Microchip Technology)United States of Americarecord ↗ 32 megabit flash memory, marked Atmel AT49BV322DТ 70TU 1116
  • XILINX XC2V1000 FG456AGT1225 D1488220A Virtex TAYWAN Built-in integrated circuit Xilinx Inc. (AMD)United States of Americarecord ↗ Built-in integrated circuit, marked XILINX XC2V1000 FG456AGT1225 D1488220A Virtex TAYWAN
  • INTEL i386 EX JA80386EX25 L239MA23E TB Built-in microprocessor Intel CorporationUnited States of Americarecord ↗ Built-in microprocessor, marked INTEL i386 EX JA80386EX25 L239MA23E TB
  • Board BTMRS4-301
  • CompactFlash 133x 16 Gb Memory Card Transcend TranscendTaiwanrecord ↗ Memory Card Transcend, marked CompactFlash 133x 16 Gb
  • Board BTM33-408
  • 4CA9TOK LVC32A integrated circuit Texas InstrumentsUnited States of Americarecord ↗ integrated circuit, marked 4CA9TOK LVC32A
  • CORTINA WJLXT971ALE A4 C448D00A transceiver Cortina SystemsUnited States of Americarecord ↗ transceiver, marked CORTINA WJLXT971ALE A4 C448D00A
  • LINEAR LT1587 CM-3.3 5056350 Line stabilizer Linear Technology Corporation (Analog Devices)United States of Americarecord ↗ Line stabilizer, marked LINEAR LT1587 CM-3.3 5056350
  • H1102NL 1438-PP Telecommunication transformer Pulse Electronics CorporationUnited States of Americarecord ↗ Telecommunication transformer, marked H1102NL 1438-PP
  • BT33-205 v 4 board
  • PAUAA LVTH162244 16-bit buffer and line driver, for low voltage applications (3.3 V) Texas InstrumentsUnited States of Americarecord ↗ 16-bit buffer and line driver, for low voltage applications (3.3 V), marked PAUAA LVTH162244
  • 4CC32NK G4 LVTH16245A 16-bit (suspended high) non-inverting 3-stand receivers, expandable for low voltage 3.3V Texas InstrumentsUnited States of Americarecord ↗ 16-bit (suspended high) non-inverting 3-stand receivers, expandable for low voltage 3.3V, marked 4CC32NK G4 LVTH16245A
  • S29GL256P11TF102 530BB667 B 05 SPANSION Flash memory Spansion (Cypress Semiconductor, Infineon Technologies)United States of Americarecord ↗ Flash memory, marked S29GL256P11TF102 530BB667 B 05 SPANSION
  • MAXIM MAX211EEA1 1533 Linear receiver driver Maxim Integrated Products (Analog Devices)United States of Americarecord ↗ Linear receiver driver, marked MAXIM MAX211EEA1 1533
  • CY7C1069DV33 -10ZSXI 1525 622721 integrated circuit Cypress Semiconductor (Infineon Technologies)United States of Americarecord ↗ integrated circuit, marked CY7C1069DV33 -10ZSXI 1525 622721
  • 4CC32NK G4 LVTH16245A 16-bit non-inverting 3-state receivers designed for low voltage 3.3V Texas InstrumentsUnited States of Americarecord ↗ 16-bit non-inverting 3-state receivers designed for low voltage 3.3V, marked 4CC32NK G4 LVTH16245A
  • 28CL90K AS760 G4 integrated circuit Texas InstrumentsUnited States of Americarecord ↗ integrated circuit, marked 28CL90K AS760 G4
  • Function module BT33-205 No. 1 (2-4 - identical modules)
  • B152915 29LV040CQI-70G 3S343000 4 megabit flash memory Macronix InternationalTaiwanrecord ↗ 4 megabit flash memory, marked B152915 29LV040CQI-70G 3S343000

Part records and photos: HUR War & Sanctions, Ukraine's Defence Intelligence database of foreign components found in Russian weapons, and the other sources named on each part. A marking, date code or country is given as the source records it.
